Description
5Kwh Powerwall 48v 100ah Module
The LFP based 5 wkh 48v 100Ah are a great dynamic possibility which can be expanded in series as well as parallel, according to the need Like 48v 200ah by 2pcs for 10Kwh. The modular design of battery cabinets makes it useful to meet higher energy storage capacities. Add more modules will able to support higher current requirement. This ESS lithium-ion battery is based on various standard modules & comes with optimum flexibility to design customized modules & comes with optimum flexibility to design customized modules to fit different environment in door. It proves to be the safest battery with modular design in a true sense.
BMS relay solution
OSM48100 48v 100ah Module comes with built in BMS. Different from any other mos BMS. OSM apply with relay BMS solution. This make sure the battery system much more stable and long life.
- Over temperature cutoff
- Over Voltage cutoff
- Short circuit protection
- Over charge/ discharge cutoff
- Over current cutoff
Specifications of 48v 100ah Module:
Model |
Wall Mounted 5.2kWh LiFePO4 Battery Pack |
Capacity Energy |
5.2kWh |
Capacity Ah |
100Ah |
Suggested SOC |
5%~100% |
Usable Capacity |
4.8kWh |
Nominal Voltage |
51.2V |
Operation Voltage |
46.4V – 57.6V |
Maximum Charging/Discharging Current |
100A/100A |
BMS |
Robust Multi point monitoring BMS pre installed |
Life Cycling (0.5C 25℃) |
5000 cycles |
Warranty BTT |
10MWh per kWh |
5 years, whichever comes sooner |
Operation Temperature |
0℃ ~ 45℃ |
Storage Temperature |
-20℃ ~ 35℃ |
Weight |
50kG each pack |
Dimensions |
537x450x 165 mm |
Scalable |
yes |
Certifications |
MSDS, UN38.3, RoHS, IEC62619, UL |
Communication |
RS485, CAN or RS232 for hybrid inverters |
Video show on Youtube
Features of OSM48100 48v 100ah Module lithium ion battery bank
OSM48100 makes residential battery storage to a new level. OSM 5 kWh Lithium-Iron Phosphate Battery (LiFePO4), combining superior lithium-iron phosphate technology to provide a better solution to solar energy storage.
The LFP 5Kwh OSM48100 features a battery management system that integrates multilevel safety features including overcharge and deep discharge protection, voltage and temperature observation, cell monitoring and balancing, and a built-in accessible 125 Amp DC breaker On/Off switch. This high-performance Fortress Lithium Battery has a large power capacity, with a fast charging and continuous discharge power, creating a 98% rough-trip conversion. The advanced Lithium Ferro Phosphate (LFP) technology operates a wider temperature range to deliver the most dependable performance. LFP has been proven to be one of the safest Lithium technologies in the industry and is manufactured to the highest standards.
The OSM Lithium-Iron battery is lighter, more compact, and more powerful than traditional lead-acid batteries. Our battery is designed to replace conventional solar battery storage products such as Sealed, AGM, or Gel batteries, utilize your Lithium-Iron battery in off-grid applications, solar energy storage, and more!
LiFePo4 48v 100ah Module Replace your old Battery system.
The initial charge of a disposable battery does attract it as a better buy product. But these batteries die down after certain number of usages. The rechargeable batteries are good enough till they can be recharged. But rechargeable batteries also drain over time. Lithium LFP batteries have a greater thermal stability and long-life span compared to other rechargeable batteries. You can plan to buy LiFePO4 battery which is an extremely stable lithium battery. Apart from longer lifespans these batteries are also not prone to overheating and have a greater tolerance to harsh environmental conditions. Like lead-acid rechargeable batteries lithium batteries are also composed of many cells. Buying OSM48100 48v 100Ah LiFePo4 battery is an extremely simple and efficient idea to save hundreds of your hard-earned dollars.
Environmental concerns
Disposable batteries contain harmful chemicals like nickel, lead and mercury that could pollute the environment. Rechargeable batteries also contain harmful elements but the reusability of these batteries prevents the frequent disposal of the same compared to that of disposable ones.
Longer lifespan, no maintenance, no gas emissions, deep lifecycles and less environmental impact definitely makes rechargeable batteries better than your old batteries.
These solar batteries are rated to deliver 5 kilo-watt hours kWh per cycle. Check your power bills to find the actual kWh consumption for your home or business. Find the average per day and the peak daily kWh consumption. We have solar battery packs available that provide power storage from 1kWh to more than 100 kWh.
What is a Kilo-Watt Hour?
A kilo-watt hour is a measure of 1,000 watts during one hour. The abbreviation for kilo-watt hour is kWh. So 1,000 watts during one hour is 1 kWh. The power company measures energy in kWh in order to calculate your monthly bill.
How Many kwh Do You Need for your house?
The average home uses 900 kWh per month, or 10,800 per year, according to the U.S. Energy Information Agency EIA. That means the average power required per day is 30 kWh. Now, when sizing a grid-tied solar battery system for daily usage, you will want a system that can deliver up to 30 kWh, or possibly more for peak usage days. However, if you also want the system to provide off-grid backup battery storage, then you will typically choose 3X to 5X the daily average, or 90 to 150 kWh. This should provide ample storage for complete system autonomy in case of an extended power outage of 3 to 5 days. Combine the battery storage with a PV solar panel system to ensure that you will have a renewable power source to keep the batteries charged.
